Used to spread the load of the stabilizers, these pads create a more stable and secure base when operating the crane.
| Item | Value |
|---|---|
| Model | Size (mm) / Thickness (mm) / Static load (t) |
| COP-4040 | 400 x 400 / 30 / 15 |
| COP-5050 | 500 x 500 / 40 / 25 |
| COP-6060 | 600 x 600 / 50 / 35 |
| COP-8080 | 800 x 800 / 60 / 60 |
| COP-1010 | 1000 x 1000 / 70 / 90 |
| Property | Value | Test method |
|---|---|---|
| Material | Virgin UHMWPE, 3.5 - 9.0 million g/mol | ASTM D4020 |
| Density | 0.93 - 0.945 g/cm3 | ISO 1183 |
| Tensile strength at yield | 20 - 25 MPa | ISO 527 |
| Elongation at break | > 300 % | ISO 527 |
| Charpy impact, notched | > 100 kJ/m2 | ISO 179 |
| Shore D hardness | 62 - 66 | ISO 868 |
| Coefficient of friction vs steel | 0.10 - 0.22 (dry) | ISO 8295 |
| Service temperature | -169 C to +80 C | - |
| Water absorption | < 0.01 % | ISO 62 |
